2000rpm Sludge Dewatering Decanter Centrifuge 3 Phase Continuous
Product Details:
| Place of Origin: | CHINA, JIANGSU |
| Brand Name: | HUADA |
| Certification: | GB/T19001-2016/ISO9001:2015 |
| Model Number: | LWS |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD40000-150000/set |
| Packaging Details: | Standard with wooden pallet and poly film wrapping |
| Delivery Time: | 50 work days |
| Payment Terms: | T/T, L/C, Western Union |
| Supply Ability: | 100 sets per month |
|
Detail Information |
|||
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Centrifugal Type: | Decanter Centrifuge |
|---|---|---|---|
| Discharge: | Scroll Discharge | Machine Control: | PLC Control |
| MOC: | Stainless Steel | Certificate: | ISO9001 |
| Operate: | Automatic Continuous Operation | Explosion-proof System: | Optional |
| Highlight: | 2000rpm sludge dewatering decanter centrifuge,Stainless steel 3 phase centrifuge,GB sludge dewatering decanter centrifuge |
||
Product Description
LWS 3 Phase Eco-Friendly Large Capacity Continuous PLC Control Sludge Dewatering Decanter Centrifuges
The centrifugally casted duplex stainless steel bowl and the tungsten carbide hardened tiles on the solids conveyor maximize the centrifuges operational service life between overhauls. The features replaceable ceramic/tungsten carbide inserts at the feed distribution and solids discharge zones. The unit also has Tungsten Carbide plows to continuously clear the solids discharge area. All bearings fitted to the centrifuge are SKF premium brand bearings for extended service life and reliable operation
Technical Parameters
| Model | Bowl Diameter (mm) | L/D | Bowl Speed (r/min) | Separation Factor | Power of Driving Motor (kW) | Weight (kg) | Dimension (L×W×H) (mm) |
| LWS355*1460 | 350 | 4.17 | 4000 | 3130 | 22-30 | 2200 | 3450*1010*1030 |
| LWS420*1680 | 420 | 4 | 3600 | 3050 | 30-37 | 4000 | 3500*1450*1300 |
| LWS530*2120 | 530 | 4 | 3200 | 3040 | 45-55 | 5500 | 4100*1600*1450 |
| LWS720*2880 | 720 | 4 | 2000 | 1610 | 110 | 11000 | 5300*2050*1750 |
